Duplex Built in 1900. What kind of heating/cooling to choose?

last month

Hello all, brand new user here.

I just purchased my first rental home. It’s a duplex with a top and bottom unit.

There is no forced air system in the home. There are the remnants of an old coal heater in the basement and some now-closed-off chimneys in the rooms above. I’m in West Virginia and temperatures range from single digit lows to 100° highs over the year.

Both units of the duplex have an upright gas-powered space heater, as well as one electric floorboard heating unit per floor that hardly puts out any heat.

I am exploring options for heating/cooling systems. Also, I have absolutely no idea what I’m doing so treat me like an idiot, because for now that’s what I am.

Ductless mini-split seems like a good option. But maybe have a traditional forced air system installed? Or other options might be better? Please, all advice is welcome. I want to get this place up and running ASAP.

Thank you.

Sort by:Oldest

Comments (10)

tigerdunes
last month
Is nat gas service available to the duplex?

how would you describe the insulation and building qualities of the duplex, ie ext doors, windows, r rating for walls, attic? Is there a basement or crawl space?..

IMO
Travis Metz
Original Author
last month
Natural Gas is available.

I don‘t know enough about what constitutes “good” insulation to say whether or not what I have is good (remember, I’m an idiot), but... I would say it’s not very good If I had to guess. Very old house. Plus, there is a big basement with dirt floor, and an attic as well.
Related Discussions
radiant floor heating in two story home?
Q
Comments (21)
When choosing in-floor radiant heat (IFRH), you are choosing to limit your flooring options. There are MANY floors that do NOT work over top of in-floor radiant heat. Cork is one of them. Cork blocks so much heat it negates all the warmth being produced by the system. Solid hardwood has issues over IFRH. Vinyl doesn't like sitting over IFRH. Engineered hardwood can work. Carpet works. Tile/concrete/stone always works. I would suggest you choose your FLOORING before you go much further with the IFRH. I've saved clients TENS OF THOUSANDS of dollars of installation costs. The 6mm cork underlay + cork floating floor + regular heating systems = more energy efficient, more comfortable home than with IFRH. I've seen 6mm cork underlay + 11mm cork floating floor ($4.50/sf total material costs) add 7 Celsius (12 F) in a basement (1100sf basement with ONE heat vent in N. Saskatchewan). So long as you have a regular source of heat, the cork will keep the heat IN the room. Good luck. Those installation cost for IFRH are IMPRESSIVE to say the least!
...See More
Buying a 1900 Home
Q
Comments (5)
We are in the process of moving out of our 1913 home. We lived there for 16 years, and spent a lot of that time doing renovations and improvements (which more than doubled the value of the home). We did a lot of the work ourselves. Look at insulation -- is there any? Our house had no insulation in the exterior walls, and a single layer of fibreglass batts in the attic. We added insulation to the attic right away, and then over the years did one room/area a year. We carefully removed the trim and repaired/repainted it, stripped the exterior wall lath & plaster, added rigid foam insulation with resilient channel studs (to minimize loss of interior space), then drywalled and replaced the trim. We had the windows replaced with low E/argon windows as we went. This has saved us a lot on heating/cooling bills. What we did was use thrift shops and second hand stores for decor while we saved up to finish the renos.
...See More
Need to know if there is radiant cooling like the radiant heating
Q
Comments (17)
Cooling works very effectively with cool fluid flowing through pipes in things like vehicle engines, power station generators, nuclear reaction cores, etc., but why anyone would seriously consider its use in the home in most circumstances, is lost on me. (It's utilizing conduction mainly, but bear with me.) As Home Reborn mentions, the cooling and heating process is the movement of energy in the form of heat. To cool something, you are removing energy. To heat something, you are adding energy. Heat energy transfers in three ways: convection, conduction and radiation and how efficiently it does this is a function partly of delta T, or difference in temperature. To add heat to a room, you can take advantage of a small, concentrated high energy source and disperse the energy through radiation, convection and conduction. To cool a room, you have to take a large volume of air and run it past a concentrated, low energy plate and extract the heat by really the only method that is effective: conduction (ie. HVAC coils). To try and do this with radiation and convection at small delta T can be done if you try really, really hard, but it's ridiculously expensive, highly inefficient and ineffective, grossly impractical and bordering on insane for the intended result while creating a maintenance nightmare and wasting an incredible amount of money. You are far, far better off investing your money in trying to avoid the room becoming hot in the first place (a cave) with good building techniques and effective insulation and utilizing an off-the-shelf HVAC system designed by professional engineers who know what they are doing.
...See More
POLL: How do you keep your home cool in the summer?
Q
Comments (116)
Way to Keep Your Home Cool in Summer. https://www.newcentralairconditioner.com/ Skip the AC, Increase the Airflow. In many cities, the biggest barrier to comfort is stagnant, humid air. Air conditioners remove some humidity and get the air moving, both of which can be done without the expensive noise of cooling the entire house. Create cross-ventilation by opening windows and placing fans at both ends of your house or apartment, with one fan facing inward and one facing outward to draw the air through. If you have a basement, use a dehumidifier to draw the humidity out of the air and keep the basement cooler and more resistant to mold. That will keep the ground floor cooler and prevent the growth of unhealthy or toxic mold during those damp summer months.
...See More
tigerdunes
last month
If mine, I would start with getting an insulation contractor to survey your duplex, find out what you have, make a recommendation for upgrade, and get a cost. Second, with a basement and attic, I will assume that ductwork could be installed. Two systems, one for each apartment. For an older home, think you will be better off with gas furnace/AC systems as opposed to mini splits. as to building qualities, you need good windows and ext doors. Good Luck. You have a big project in the.making. Is your duplex habitable as is?
mtvhike
last month
Are you planning for this to be a rental for both apartments or are you going to live in one?
Travis Metz
Original Author
last month
Tigerdunes, thanks for the insulation advice.

For my own understanding, why would gas furnace and AC be better than mini splits in your opinion?

The duplex is habitable Except for it’s too cold. There is a nat gas space heater that is not yet active, but I am skeptical it will be strong enough to heat the entire unit. I’m getting it activated in 12 days to see. If it’s powerful enough, I’ll not need to upgrade, but I doubt it will be. Also, I know good heat/ac would likely raise rent a bit, and certainly improve resale value.

It will be exclusively a rentaL.
kevin9408
last month
last modified: last month
I'd recommend looking into a High Velocity HVAC system. They have pros and cons but easier to install since the duct work consists of 2" flexible tubing throughout the house and doesn't require much tearing into walls to install. I'm not trying to sell it like some do with their love affair with mini splits, but just giving you an option to look into.
mtvhike
last month
How noisy is a High Velocity system?
kevin9408
last month
Depends on installation and number of outlets but a big old house it the perfect application. Installed right 25 to 29 dB.

https://www.youtube.com/watch?time_continue=78&v=JmIRCN9F7v8&feature=emb_logo

Compared to an decibel rating of 21 to 32 db's for an average mini split.
tigerdunes
last month
For an older home, I think gas furnace/AC is preferred over mini splits for comfort and operating cost. But it would be helpful to know your rates both for nat gas and electric. Try to get an insulation contractor in to survey your home. You need good DP windows and ext doors for your duplex.

TD
fsq4cw
last month
Since it's a duplex with one unit to be rented, I'd install two separate - and separately metered systems regardless of what you install.

Have the tenant pay for their own heating & air-conditioning!

IMPO

SR
