Build your own walk-in cooler?

13 years ago

Hi Everyone,

For those of you who have taken a corner of your barn, or some building, and built your own walk-in cooler, I would love to have some suggestions on what materials are needed, and also how efficient these are to run. I am at the point in my business where a cooler would be very beneficial for holding my flowers a bit longer. Especially in-between market days and also for florists. I find when all the lilies are coming in, that's when the heat hits and I just watch all those beautiful lilies blow open in the field. It seems the hottest, muggiest weather hits when I would prefer it didn't. Good for the annuals, not so good for the lilies.

I'd like to build this thing right the first time around, so would appreciate some suggestions from those of you who have been using one for a while. Thanks very much, and I hope all of you have had a great season, and are still cutting!

Cheryl

Sort by:Oldest

Comments (21)

elainect5
13 years ago
Go to this farm site
http://flyingbeet.com/
and read about CoolBot in the "Innovations" listing. The site containsdetails on room size, insulation thickness, etc.
flowers4u
13 years ago
Cheryl,
The marketfarming listserve has lots of info in the archives about building your own. But, I went with a used walk-in this year! The "cooler guy" had the best advice...stake out your spot (i.e. size you want) and put buckets in it, leaving room to walk and room for the thickness of the walls and concrete pad). I had thought 8' x 10' would have been sufficient! I'm so happy I went with a 10' x 12' instead (9' tall with the compressor on top)! I fill it up...five buckets of sunflowers take up lots of room!

I think a good refrigeration person can really help. Coolers are designed for different applications! Flowers like a bit of humidity...soda/beer do not! So, specifying flowers is key!

The cost of this cooler was approximately 50% of the cost of a new one, including a roof and concrete.

I can now pick lilies as needed, and other filler flowers and have them when I need them instead of "losing them" in the field when I don't have time to pick them or sell them!

Another thought - look for a used floral cooler from flower shops closing...I also have a small two door Bush floral cooler...which has saved me for a long time...I use it now for "short" stuff and wedding/special order flowers!

Good luck,
Wendy
Related Discussions
Would you put a skylight in your bedroom? What about in your walk in
Q
Comments (22)
Studies show that the less light in a bedroom, the better the quality of sleep. I have both skylights and Velux tubes in my home, because we, too, love lots of light. But we said a BIG NO to either one in our bedroom. We had two long windows in our previous home's master closet and we experienced quite a bit of fading problems, even with the windows having closed blinds. So none for us in the closet, either, just plenty of lighting switches. If you, or future buyers don't like a skylight once it is installed, the roof is already messed up. Still, it's your home and unless you plan to sell it in the near future, do what makes you happy.
...See More
Want to build my own home
Q
Comments (6)
Even if you are a 100% cash build with a 50% contingency fund, it's still smart to finance the home. That gives you some professional assistance in the financial disbursements, and the bank will require inspection milestones in addition to the municipality inspections. It takes some of the burden of being ''the heavy'' in the trades management away from you. You have ''the bank'' to satisfy as the barrier to paying them for any crap work. Most GCing is herding cats while policing a kindergartner playground. Any help you can get with either portion is good to have. A bank will also likely be a bit stricter in their timeline requirements than your municipality will be, which is also a good thing in an owner builder situation. It forces you to be more organized and motivated. OB builds tend to drag on for much longer than a pro build, because of the lack of experience in sequential scheduling and the inability to attract the better trades with the project only being a one off build situation. The architect who will design the home for you will need to walk the site and view the sun path, views, obstacles, and study the setbacks and other regulations that govern our property. It helps to bring a list of tasks that you want the home to do, and the adjacency relationships. Prioritize the needs vs wants. For instance, if your other half is a ER nurse who works the night shift, having the bathroom and master closet be well separated from the bedroom with a secondary exit that doesn't go through the bedroom might be a priority. If you have toddlers, having a large bedroom for them to share near your bedroom may be a priority at this stage of life. If you have teens, avian enough external parking for their vehicles along with the garage parking for you may be needed. Don't toke a sandwich to a banquet when you meet with the architect. Take your ideas, Houzz pictures, and other inspirations. Not amateur sketches of floor plans. Let the Pro o the job he was trained to do. What Your Contractor Can't Tell You, A Pattern Language, and What Not to Build are all good reading for the beginning stages.
...See More
Building an Addition now. What is your opinion Master Bath tile?
Q
Comments (6)
For long term items, wood floors, shower walls ect IMO spend the extra funds get what you like in the best quality you can. Save money on things that are easily changed out and upgraded later like light fixtures. When needing to make a decision on price vs what I envisioned I ask myself if I would buy my house if X was missing? Or if the extra money spent would be noticeably worth it. Upgraded to clear glass for the master shower, went with one inch marble for hall bath vanity counter still looks beautiful saved a bit there. Making all the decisions stressful, but controlling the project worth it.
...See More
Front Hall Closet? To build or not to build.
Q
Comments (10)
Doesn't it get cold in Utah, and will you ever have guests? Assuming the answer to those two questions is yes, and that your guests will come through the front door, Will you want to take their coats at the front door, and then trudge to the back of the house with their heavy outerwear, coats, hats, gloves, etc to the mudroom to hang them up? Or wouldn't you prefer to hang them up in a closet near the front door (in which you can also have a holder for umbrellas, a tray for boots, a shelf for hats, etc). You can also have in your entryway a little bench for people to sit down on to take off their boots in snow season. (If your entry is too small for this you can get a folding bench or chair that you keep in the closet and just set out during inclement weather when you expect company to be wearing boots. And by the way- I am not sure any climate is immune from moths. You may not want a cedar closet which doesn't prevent moths completely anyway, but please take the usual precautions against moths, no matter where you live.
...See More
susanmc5
13 years ago
Hi Wendy: I am interested in your new cooler as I am in the planning process myself. What did your cooler guy do about the humidity issue for your cooler? SusanM
flowers4u
13 years ago
Susan,
He installed a special coil that generates more "humidity" - on hot days, it fills up a 5-gallon bucket! The fans also need to be really good! I found one had quit and boy did the statice get mold in about 4 days...and it shouldn't have! We also have muliple thermometers throughout the cooler to monitor the temperature.

I now am figuring out the best shelving arrangements/configurations!
Wendy
Fundybayfarm
Original Author
13 years ago
Wendy,
That was excellant advise. I would not have thought to take buckets and figure out the size. Plus, you eliminated my thoughts of going to the pepsi plant to find out about those coolers. Thanks very much. Do you mind me asking how much it costs you to run your cooler for the summer? It sounds like it will cost a lot to do it right, with the cement floor and all, but we do loose a lot of flowers without it. At what temperature do you keep the cooler? Thanks for all your help,
Cheryl
flowers4u
13 years ago
Cheryl - I try to keep it at 38...but its warmer near the door! I think - I don't know for sure, since we don't have a separate power meter - that the cost is about $50/month to run the cooler. New coolers were around $9500 without installation, concrete, electricity. I spent around 50% of that. But - do check ebay, capital press, etc. and floral shops for used floral coolers. My 2-door cooler that I purchased 5 years ago is great and has been sufficient up until last year!
Good luck,
Wendy
Fundybayfarm
Original Author
13 years ago
Wendy,
Thanks very much for all the information, it sounds like you saved a lot of money and have a very nice cooler.
Cheryl
kitkat_oregon
13 years ago
Wendy, I wanted to ask you what your cooler walls are made of. Did you line the inside with melamine or some other water proof material? Also, did you use one of those Coolbot things? Thanks, Kat
flowers4u
13 years ago
Kat - I didn't build mine...found a great refrigeration guy (from Salem) who has lots of used coolers. He had a 9' model (gave me the extra panels too for "when I need to expand!") So, the inside walls are lined in aluminum I think. Now, I'll need to take a picture for you! I never did...sorry about that. It looks better now that our 3' of snow is almost gone! Glad we put a roof on it after all...one that is 3' wider!
Wendy
bfff_tx
13 years ago
This is what I did. I checked into used everywhere I could think of and in the end, I gave up, it was frustrating and disheartening. I ended up buying brand new in April of 2007 from a Tx company on the internet. They gave me customer references that checked out great so I got a 8'x10'x7'.6"H floral cooler with a outdoor rated penthouse refrigeration unit. I also planned it out on the floor as Wendy described.
My hubby and a friend put it together for me in less than a day and hubby hooked it up to the power. It didn't cool.....
Had a refrigeration tech out here in two days, he fixed it (nothing major, freon leak) under warranty. Worked like a charm every since. Runs at 38 with 75-80% humidity.
Total cost, free delivery & ethylene filter = $4,180.00
BARGAIN. It costs approx $50/month to run.
{{gwi:626240}}
It does sweat (moisture on concrete), one of the joys of the texas climate
{{gwi:626241}}
Penthouse refrigeration Unit on top of cooler
{{gwi:626242}}
Ethylene Filter
{{gwi:626243}}
* Wendy - Stainless Restaurant Cart with adjustable shelves
{{gwi:626244}}
Cinder blocks and planks - gives you two levels for buckets. The floor and the plank.

So I recommend to anyone looking for a cooler, to check these guys out. They have a wealth of info on their home page too.
Cheers Kim
Billabong Fresh Flower Farm

Here is a link that might be useful: Walk - In Floral Coolers
kitkat_oregon
13 years ago
Kim, if you get the odd sensation of a kind of creeping green feeling coming your way, it's me, being very envious of your cooler! Ooo, I would love one like yours. Beautifully organised too. Thanks for the link. Kat
flowers4u
13 years ago
Kim - very nice! I like it in your shed too! We had to build a roof for ours...but glad we did, with the winter we've had!
I learned something from the site you gave..about ethylene gas filter...I don't have that! I'm going to be asking though. I know about ethylene and not storing fruit, etc. in the cooler when flowers are in it, but didn't realize there was a specific filter!

Very nice!!
flowers4u
13 years ago
Cheryl, Kim, Kat - and everyone...finally had a chance to get pictures taken, when it wasn't too messy! I have shelves, but just don't have them in the cooler yet. The cooler is 10 x 12 x 9' tall. I still don't have the lights installed, didn't get them until right before it snowed...so need to get that done and fill in around the edges with more rock.
Side view of cooler
{{gwi:626245}}
Front of cooler
href="http://smg.photobucket.com/albums/v356/flowers4u/2008%20flowers/?action=viewÂ¤t=IMG_3238.jpg"; target="_blank">{{gwi:626246}}
Inside w/dahlias and apples!
{{gwi:626247}}

Water bucket-fills up on hot days!
{{gwi:626248}}

(sorry about the sideways pics...I couldn't get them to stay rotated and posted that way!)

The "cooler guy" still needs to finish the inside bottom...he was unable to come back last fall and I had it full anyway!
Hope this helps!
Wendy
kitkat_oregon
13 years ago
Hi Wendy, great cooler! We have just purchased a new piece of land and are busy clearing for the market garden and the floral cooler is going to be incorporated into the basement of the house, (yet to be built of course!) but I am beginning to think that a free standing one outside is perhaps a better way to go. Access to the basement from the outside is going to be easy and there will be a workroom also so maybe inside is better, any thoughts? Tks Kat
flowers4u
13 years ago
Kat -
My two cents...I'd love to have the cooler in a shed structure like Kim's. I'd reserve basement space for starting seeds/plants - since more than likely it will not freeze in that location! I make a mess all the time and would hate to add that to what we already track into our house! We did ours freestanding because our "barn/shed" wasn't big enough or structurally able to support it. Two years ago I actually looked at barn/shed plans and had planned to incorporate a walk-in cooler near an entrance to the shed from the field. But...that type of structure was more than my budget...some day.... :)

Hope that two cents is helpful!
Wendy
kitkat_oregon
13 years ago
Wendy, two cents is always worth so much more! Do you have a work space near your cooler where you do your bouquets and preparation? I am trying to keep everything located within comfortable manoevering distance. Keep adding the two cents, please. Thanks, Kat
flowers4u
13 years ago
Kat - I'll try to get a picture this weekend. My "barn" is less than 10' from the cooler. I do have to have my door switched...it opens the wrong way from the barn..ties up space and takes more steps...not a good thing when Im tired! Have a great weekend.
Wendy
cindyandterry_mac_com
10 years ago
We bought a florist building and have the flower cooler equipment - we will sell the compressor and two chiller coil units (they are virtually new and in terrific shape - $15,000 new) for $3000. We will include two heavy, insulated cooler doors and two additional coil units. Located in Charlottesville VA - must pick up!
flower_farmer
10 years ago
Cindy,

Contact Judy or Linda at the attached link. Flower farmers belong to this organization. There are several in your area. The directors of ASCFG will most likely post the information on the Bulletin Board to let growers know about this super deal.

Here is a link that might be useful: ASCFG Contact Information
angssite_hotmail_com
9 years ago
I have 2 very heavy antique wooden/insulated cooler doors and frames for sale with 2 square antique cooler windows and frames & a compressor. $4000 obo--can be purchased seperately---Manitowoc, WI. must pick up or arrange for shipment.
angssite_hotmail_com
9 years ago
I have a walk-in, display cooler for sale--nice, works great(with compressor)--without floor(but so easy to build)--$2000 o.b.o.-you can see it at the Sheboygan,WI. craigslist--under business--(have moved my location and was not able to use such a large cooler :))
