New Pool Build-Orangevale, CA
My husband and I have been working on a pool design for almost 2 years now and we are finally pulling the trigger and starting our dream backyard. My home is on 1.50 acres and nothing has been done to the backyard other than some concrete work around the house when we first moved in. We are going with a large pool so that when it's finished it does not look like a pond in my backyard.
Any advise or recommendations would be greatly appreciated.
Pool Specs:
45' x 30' 6" x 23' 6" free form pool
915 sq ft pool
10' x 15' Cabo Shelf with 2 umbrella sleeves
3' to 8' deep
Salt water pool
Pebble Sheen in Aqua Blue
3x3 water line tile-may upgrade this to 6x6 tile for $600 more.
30' of 42" Raised Bond Beam with Stone Face and Stone Cap (right & left side of pool on back wall)
16' of 30" Raised Bond Beam with Stone Face and Stone Cap (middle of pool on back wall)
2-36" Clear Sheer Descent Spillways
3-24" Clear Sheer Descent Spillways
5 Tons of Boulders
Notched Beam for Boulders
Jump Rock Boulder with Step Rocks at deep end
3-LED Color Changing Lights
Equipment:
Pentair 520 Filter
Intelliflo VS Pump
Sand Shark Pool Cleaner
Seperate 1HP pump for 36" Spillways
Use Intellifo Pump for 24" Spillways
Solar Stubs at equipment pad
2-Skimmers with concrete caps
Autofill with overflow-owner to tie into drain
Concrete:
1450 sq ft of stamped no color concrete decking with 6x6 grid and band on outside edge
60' of 6" step riser in walkway to tie existing concrete with pool decking
4' x 6' Equipment Pad
Here is a link that might be useful: YouTube Video
Comments (91)
- 12 years ago
Raised bond beam wall complete - wet down with a hose to show what It will look like sealed, although it won't be quite as dark.
Related Professionals
Ashland Landscape Architects & Landscape Designers · York Landscape Architects & Landscape Designers · Louisville Landscape Contractors · Greenville Landscape Contractors · Marietta Landscape Contractors · Winona Landscape Contractors · Laconia Landscape Contractors · Westerly Landscape Contractors · Branson General Contractors · McAlester General Contractors · Lawrenceburg General Contractors · North Adams General Contractors · Saginaw General Contractors · Blythe General Contractors · Riverside General Contractors- 12 years ago
- 12 years ago
- 12 years ago
Still have to install the heat pump (wrong one was ordered), replace one LED light (wrong one was installed), finish buttoning up the plumbing, and balance the chemicals. Almost there! Can't wait to see the sheer descents pouring out of the walls and the colored LED lights turned on. Should be swimming by next weekend. We must have good water here, because the pool did not turn green to start like many others I've read about online.
- 12 years ago
This is the best picture that represents the color of the pool as it is right now with no chemicals added yet. (Just finished filling)
- 12 years ago
- 12 years ago
- 12 years ago
11 years ago
10 years ago- 10 years ago
- 10 years ago
