Polycarbonate panels failing

12 years ago

Harbor Freight polycarbonate panels aren't the only ones subject to failure. All the 6mm roof panels we on our roof have cracked open. They were installed when the greenhoue was built by a major greenhouse company in the spring of 2002 and are now in terrible shape. It seems the 10 year warranty will be honored this time but when they put the new panels on, they won't honor the new panels' warranty unless they install a 26 inch long curved piece of glass at the roof-side curve. It must be that the stress at the curve is causing failures on their panels. I don't know if this is where others have had failures but they are going to have to be replaced before winter. See photos at:

http://s310.photobucket.com/albums/kk436/ALU6/

Sort by:Oldest

Comments (9)

greenhouser
12 years ago
Wow! What a mess. The discoloring also looks horrible. I guess they're not made to bend like that.

My HFGH is over 2 years old and still looks brand new. We cover it from late April until early October. We also cover the Rion.
laserfan
12 years ago
Were these panels "pre-curved" i.e. formed that way wherever they were manufactured? Or bent-over on-site? In any case it looks like stress accelerated their demise for sure.

I wonder too if mfrs aren't experiencing more "premature failures" than expected given the higher levels of UV reaching Earth's surface these days.

I would say to anyone using polycarb (plastic) that they absolutely need to cover those panels that take a direct hit of sunlight, especially during summer when the sun is highest. I figger ol' Sol is laughing at us thru the depleted ozone layer...
Related Discussions
polycarbonate patio roof
Q
Comments (2)
Are the polycarbonate panels you installed rated to prevent UV rays from coming through? I ask because it is possible that they allow 30% of the light to come through, but the UV rays that carry the heat are still fully getting through. If the polycarbonate panels are rated to prevent a percentage of the UV rays, they would likely then help keep the patio cooler rather than warmer. If you need new polycarbonate panels, we offer several tints (allow various percentages of light through) that also provide 100% UV protection - http://www.postframeaccessories.com/polycarbonate.html
...See More
Help tub faucet install fail or fine?
Q
Comments (22)
Grab a measuring tape and measure the distance between the faucet and the right handle, then the distance between the right and left handle. The photo looks as though the handles were installed with, perhaps, an 6" spread. The right handle looks like it unevenly spaces to the faucet (it should be 6" inches as well). Each element should be equidistant to the others for this install. If not, a serious sit down with the contractor may be in order. Now, to see if this is something you can live with or not, and even though the room is not finished, grab a couple of candles or a decorative dish of soaps and place them on the granite near the faucet. Try to imagine the finished bathroom with all of the decor in place. Could this simply be a unique part of the design in which you can find pride? Or are you going to have "what if's" for the life of this bathroom?
...See More
Shower glass replaced by polycarbonate?
Q
Comments (7)
2406.1 Human impact loads. Individual glazed areas, including glass mirrors, in hazardous locations as defined in Section 2406.4 shall comply with Sections 2406.1.1 through 2406.1.4. Exception: Mirrors and other glass panels mounted or hung on a surface that provides a continuous backing support. 2406.1.1 Impact test. Except as provided in Sections 2406.1.2 through 2406.1.4, all glazing shall pass the impact test requirements of Section 2406.2. 2406.1.2 Plastic glazing. Plastic glazing shall meet the weathering requirements of ANSI Z97.1. 2406.1.3 Glass block. Glass-block walls shall comply with Section 2101.2.5. 2406.1.4 Louvered windows and jalousies. Louvered windows and jalousies shall comply with Section 2403.5. "Safety of Acrylic/Polycarbonate vs Glass In 1977 the Consumer Product Safety Commission "outlawed" the use of annealed glass in doors and other areas considered dangerous - mainly glass next to doors and glass that is within 18" of the floor (ANSI Z 97.1 for Safety Glazing Materials used in Buildings). The solution for manufacturers was to replace regular annealed glass with heat-tempered safety glass. A drawback is that tempered glass cannot be cut once it is tempered so it has to be ordered from the factory to the exact size. Acrylic, on the other hand, meets the requirements of the safety regulations AND can be cut to size in our shop. That makes it a great substitute when time is of the essence." pros and cons of polycarbonate
...See More
How would you fix this design/color fail in family room?
Q
Comments (9)
Your room is lovely but what I think is throwing me off is the dark fireplace wall. It's too much of a contrast with all the whites on that wall, the red brick clashes with the reds in your carpet and you can barely see the wreath. I would make that wall into a real feature by adding built in cabinets with doors on either side of your fireplace that would go as high as just beneath the mantle. Then I would paint the cabinets, fireplace brick and mantle the same white as your trim. The space above the fireplace I'd paint the same as the rest of your room. Then put back your wreath and small frames. I also find the mirror over the couch too small. That couch is large scale so what's above should be large scale too. Go for horizontal artwork perhaps with some colour. Add a coffee table maybe in metal and glass so it doesn't visually take up a lot of space. Your drapery rods are too low, they should be halfway between window and ceiling. Good luck!
...See More
greenhouser
12 years ago
Both my Rion and HFGH are snugly covered and protected from the summer sun. The panels still look brand new on both - so far. :)
oakhill (zone 9A, Calif.)
12 years ago
Sorry about your polycarb panel problems. It may be that the design of the bend is more than is recommended. Just in looking at your photos and comparing to the recommendation, it looks like that may be at least part of the problem. The fact that the manufacturer now uses curved glass instead of trying to bend the polycarbonate too far supports this idea.

Here is a link that might be useful: polycarb bending ratios
medontdo
12 years ago
that totally sucks!! i really wanted one of them types!! but they were so exzpensive!! i'm so glad they're gonna honor it for you!! that would be so heart breaking! ~Medo
hothouse1
Original Author
12 years ago
The panels on the greenhouse were flat when the company people brought them in and they were gradually bent to the curve upon installation. The roof has always been covered by shade cloth, also supplied by the manufacturer.
babalubird
12 years ago
What a shame.

I can't thank you enough though for sharing this info and photos. We were seriously thinking about this material for our greenhouse which would be curved and subject to severe winds and very hot sun. You just saved us from a ton of grief, no doubt.

Connie
calliope
12 years ago
Yes, they'll fail with that much curvature on a straight piece of polycarb. One of my smaller g'houses is polycarb twin wall, and we actually had it designed for the spot and they sent one of their engineers down to look it over to make sure it would 'fly'. Well, I didn't have good feelings when they did a bend on mine down near the bottom. Was told it would be guaranteed. It failed within three years. We didn't even ask to have it replaced, as it would just do the same thing again. What we did was replace the lower two feet of the g'house (where they were putting the bend) with other building materials and then attached the glazing to that and just cut the cracked part off. No problems since. We are prolly on year ten or more now, and it's still clear and functional. The polycarb will bend safely over the slight arch of your typical quonset or gothic roof, but wow, bending it that much like in your pic is asking a lot.
calliope
12 years ago
The discoloration on the panels in the picture are where water has gotten between the walls of the panels and is algae. When we installed the twin wall, the instructions were to use a waterproofing tape over the open ends of the gaps before you slide them into the channels. Otherwise, even if water doesn't get in grossly, moisture will make for condensation and decrease the light transmission.
